4″ – 0.55 KW – 4SD2/12 Borehole Pump End

The Hurricane 4SD2/12 borehole submersible pump end requires a 0.55Kw submersible motor to drive it and is capable of delivering up to 10L/min at a depth of 84m.

It can be connected to 220V single phase 0.55KW borehole submersible motor.

Description

The Hurricane 4SD2/12 borehole submersible pump end requires a 0.55Kw submersible motor to drive it and is capable of delivering up to 10L/min at a depth of 84m.

Operating Conditions

  • Maximum fluid temperature : up to 35°C
  • Maximum sand content : 0.25%
  • Minimum borehole diameter : 4″ (10.16cm)

Motor & Pump

Single Phase : 220V – 240V 0.55KW 0.75HP / 50Hz or
Equip with either a standard (manual) or an automatic control box 0.55KW 0.75HP (water level sensors)

Warranty : 12 Month

According to our general sales conditions

Specifications

  • Speed : 2850RPM
  • Power : 0.55KW
  • Power : 0.75HP
  • Outlet : 32mm
  • Pump Diameter : 100mm
Output 5L/min 30L/min 55L/min
Depth 84m 72m 38m

Water Delivery Pump Curve

4sd2/12 Submersible 4" Pump Curve

Additional information

Weight 5 kg
Dimensions 54 × 11 × 15 cm
